CONSTRUCTION DATA
Conductor
# of Conductors
8
AWG
23
Conductor Stranding
Solid
Copper Type
Bare Copper
Insulation
Type
Polyolefin
Thickness
.010 in.
Color Code
BL, WH/BL, OR, WH/OR, GN, WH/GN, BN, WH/BN
Shield
Shield Type
N/A
Drain Wire Type
N/A
Drain Wire AWG
N/A
Jacket
Jacket Type
PVC
Nominal Cable O.D.
0.220 in.
Colors
Black, Blue, Green, Gray, Orange, Violet, White, Yellow
APPLICATIONS
Networking
Security
X-REFERENCE
WPW
4246
Belden
2412
TECHNICAL DATA
Voltage Rating
300V
Operating Temperature
-20 to 60 C
Flame Test
UL 1666
NEC Rating
CMR
RoHS Compliant
Yes
Max. Pull Tension
40 lbs
Max. Bend Radius
1.100 in.
Cable Weight
29 lbs
Nominal DCR
24 Ohms/1000ft
Nominal Cap. Between Conductors
15 pf/ft
Nominal Cap. Cond. To Shield
N/A
