CONSTRUCTION DATA
Conductor
# of Conductors
8
AWG
23
Conductor Stranding
Solid
Copper Type
Bare Copper
Insulation
Type
Polyolefin
Thickness
.010 in.
Color Code
BL, WH/BL, OR, WH/OR, GN, WH/GN, BN, WH/BN
Shield
Shield Type
N/A
Drain Wire Type
N/A
Drain Wire AWG
N/A
Jacket
Jacket Type
PVC
Nominal Cable O.D.
0.260 in.
Colors
Black
APPLICATIONS
Networking
Security
X-REFERENCE
WPW
4346A
Belden
4346A
CABLE PRINT LEGEND
Provideon Wire & Cable #N4P236AS 8/23 Shielded Category 6A CMR Made in USA Date Code A B C D E F G H I J 1 2 3 4 5 6 7 8 9 0
TECHNICAL DATA
Voltage Rating
300V
Operating Temperature
-20 to 60 C
Flame Test
UL 1666
NEC Rating
CMR
RoHS Compliant
Yes
Max. Pull Tension
25 lbs
Max. Bend Radius
1.300 in.
Cable Weight
37 lbs
Nominal DCR
24 Ohms/1000ft
Nominal Cap. Between Conductors
16 pf/ft
Nominal Cap. Cond. To Shield
N/A
